| Machine Size | Code | Metric (mm) |
Standard (inch) |
| Total transport length | A | 2950 | 123 |
| Total Transport width | B | 1100 | 46 |
| Total height | C | 2220 | 93 |
| Bulldozer blade width | D | 1100/1300 | 46/54 |
| Bulldozer blade height | 213 | 9 | |
| Caterpillar band center distance | E | 920 | 38 |
| Plaform clearance | 400 | 17 | |
| Standard bucket width | 350 | 15 | |
| Total length of caterpillar band | 1,390 | 58 | |
| Working Range | Code | Metric (mm) |
Standard (inch) |
| Maximum excavation height | F | 2970 | 124 |
| Maximum unloading height | G | 2030 | 85 |
| Maximum excavation depth | H | 1780 | 74 |
| Maximum vertical arm excavation depth | I | 1550 | 65 |
| Maximum excavation distance | J | 3420 | 143 |
| Minimum turning radius at front end | K | 1350 | 56 |
| Maximum excavation ground distance | L | 3380 | 141 |
| Maximum bulldozing height | M | 150 | 6 |
| Maximum bulldozing height | N | 220 | 9 |
